RYD-T Weighing Powder And Granule Filling Machine

RYD-T Weighing Powder And Granule Filling Machine

Products That Can Be Filled

RYD-T Powder Weighing and Filling Machine General Features

Features / Series RYD-T50S RYD-T120 RYD-T125 RYD-T150
Price
650,00$
1.750,00$
2.300,00 $
2.600,00$
Working Range
2 - 100 gr
50 gr - 2000 gr
50 - 2500 gr
50 gr - 5000 gr
Capasity
10-20 pcs/minute
20 LT
--
400-700 pcs/hour
Power consumption
15Watt
150 Watt
150 Watt
15 kW
Dimensions
38X32X52 cm
--
--
--
Weight
6 kg
45 kg
45 kg
45 kg
Suction Pipe
304 Stainless
304 Stainless
304 Stainless
304 Stainless

Products That Can Be Filled

RYD-T Weighing Powder And Granule Filling Machine

Nails

RYD-T Weighing Powder And Granule Filling Machine

Screws

RYD-T Weighing Powder And Granule Filling Machine

Granule

RYD-T Weighing Powder And Granule Filling Machine

Tablet

RYD-T Weighing Powder And Granule Filling Machine

Chips

  • Non-adhesive powder types, crystal products, granule products, tablets, screws, nails, granulated sugar, chips, etc. that you will make up to 5000 pieces per day. They are machines designed to be used in the filling of products.
  • They are extremely ideal machines for the filling processes of products that require weighing.
  • Our machines absolutely do not need air during their operation. For this reason, you do not need to buy a compressor as in similar machines. You can easily operate your mobile phone at the socket where you charge it. The discharge cover of the weighing pan is opened by being driven by an electric motor. Since it does not require air, the operating noise is less than comparable machines.
  • The intelligent microprocessor control card controlling the RYD-T Series Powder Weighing and Filling Machine tests the flow rate of the product several times in order to be able to fill your product stably, calculates the pouring rate of the product so that the product can give a stable weight, and continues the next filling more precisely. Thanks to this feature, our machine makes weighting more precisely than other machines. In a machine with well-adjusted product discharge channel settings, the filling accuracy will be around 1 gr even at 2.5 kg.
  • All parts of the machines are made of SUS 304 Stainless steel. In this respect, the machine complies with GMP, FDA norms. The inner sole of the machines is also stainless steel. Thanks to this feature, you can also reuse the products spilled into the machines.
  • RYD-T Series semi-automatic powder and granule filling machines emit less noise compared to similar machines. Having a special spring system prevents noise at a level that will disturb the environment during operation. In this respect, we can say that they are extremely suitable products for workshops working under apartments.
  • The working range of our machines is suitable for your fillings between 2 gr – 2000 gr.
  • It is 100% domestic production. In this respect, it is extremely accessible in terms of service and spare parts.
  • It is designed to be portable and convenient to carry. You can easily work in many jobs with a single machine.
  • Thanks to the loadcell fixing and vibration fixing screws, it is not damaged during transportation. Our machines are in full safety against external impacts that may occur during transportation.
  • It has an extremely easy to use menu. Thanks to the menu, you can work at 3 different vibration speeds. You can control the movements and production performance of the machine through the usage menu.
  • Work with very little noise. Thanks to the special spring system, our machines do not make disturbing noise during operation. In this respect, they are suitable machines especially for workshops working under apartments.

Working Method of RYD-T Weighing Powder And Granule Filling Machine

The way the machine works step by step is as follows:

1- It pours the product in the volume of 30L – 20L from the product feeding bunker into the weighing pan.

2- Randomizes the first two or 3 recharges to find out the required recharge rate.

3- It makes a short beep when it reaches the target weight, and a long beep when it is passed or missing.

4- After the weighing is finished, it waits for you to press the pedal. It will not weigh again until you step on the pedal.

5- When you press the pedal, the product opens the discharge cover and keeps the cover open until the weight on it is zero or close to zero.

6- After the cover is closed, the vibration works again and the machine weighs again.

7- If the product in the product feeding bunker decreases and the vibration power becomes high during the filling, it re-adjusts the required vibration speed after the filling, which it cannot do precisely. It tries different vibration speeds until it reaches the closest weight to the target weight.

8- If the product runs out in the product feeding bunker, it continues the vibration for a certain period of time. If it cannot complete the weight, it stops the filling by making a long beep. It does not weigh again until you press the start button after you press the pedal and empty the product in the weighing pan.

RYD-T Weighing Powder And Granule Filling Machine Other Details

  • If you request additional (optional) features for the machine you have chosen, the delivery time of the machines is within the range of 5-20 days.
  • It is packaged to be suitable for long-distance cargoes.
  • Our machines are generally in stock.
  • Thanks to the contracted courier company, the product is transported at an advantageous price. If your company has a contracted cargo company, you can choose to use that cargo as well.
  • 1 year warranty is provided against manufacturing defects.
  • At the first start-up, make sure to unscrew the fastening screws and operate.
