CYD-Y2-1000 2 Nozzle Liquid Filling Machine

CYD-Y2-1000 2 Nozzle Liquid Filling Machine

CYD2-Y1000 - Technical Specifications of 100-1000ml Dense Liquid Filling Machine

Model CYD2-Y1000
Working Range 100 – 1000 ml
Capacity 15 – 35 Fillings/Minute
Filling Accuracy ±1%
Input Voltage 220V AC
Input Current 1A
Power Consumption 10W
Air Pressure 0.4 – 0.6 MPa (4 – 6 Bar)
Dimensions 120 * 52.5 * 54 cm
Weight 32 kg
Operation Mode Pedal or Automatic
Material Stainless Steel
Energy 220V / 50HZ
Suction Pipe 304 Stainless
Suction Pneumatic Cylinder DNC Type Thick-walled, Honed Type
Nozzle Pneumatic Cylinder Square Cylinder
Sensors Mindman China Manufactured
Pedal Material Plastic Pedal
Outer Box Material Cardboard
Seal Group Silicone

CYD2-Y1000 - General Features of 100-1000ml Double Nozzle Dense Liquid Filling Machine

  1. It can fill all products with low and medium viscosity between 100 ml and 1000 ml.
  2. The flange ferrule system at the connection points of the CYD2-Y1000 semi-automatic single nozzle dense liquid filling machine allows the machine to be easily disassembled and quickly cleaned.
  3. All sealing materials, such as gaskets and seals, that come into contact with the product during filling are made from antibacterial silicone material. Thus, you establish a system that meets hygiene requirements (GMP conditions).
  4. Thanks to the precision dosing lever with a 0.5 mm pitch, it allows operation across many filling ranges with minimal deviation using a single machine. As long as the dosing setting is not changed, it continues to operate at the same measurement.
  5. The emergency button on the CYD-Y1000 semi-automatic single nozzle dense liquid filling machine allows the machine to be safely positioned in emergencies, regardless of its location. This provides a production method compliant with the Occupational Safety Law No. 6331, requiring no extra cost to comply with the law.
  6. The machine can be connected to tanks or reservoir discharges using clamps and can also suction from sources such as barrels, buckets, or jugs by dipping. It requires no extra effort to bring the product to the mouth of the machine, helping you save time.
  7. You can operate the CYD-Y1000 semi-automatic single nozzle dense liquid filling machine in two different ways according to your production speed and format. You can either run the machine in automatic mode on a timer or operate it manually with the pedal provided for free with the machine.
  8. The nozzle system has a drip prevention mechanism. This way, you will not experience dripping problems after the filling is completed. As a result, your filled bottles remain clean, and you avoid weight losses due to drips.
  9. Unlike similar products, it has a honed product suction piston. This piston allows for high-precision dosing even at high weights and minimizes filling losses. Moreover, since the piston surface is smooth, the piston seals have a longer lifespan compared to others.
  10. The built-in conditioner in the machine system protects against factors like water and rust that may occur in the air system and harm the machine’s pneumatic system. Thanks to the slide valve at the air inlet of the machine, you can cut off the air from the system without needing a different valve when you finish working with the machine.
  11. Having an electro-pneumatic system provides an advantage in achieving precise dosing and preventing weight losses.
  12. The grounding in the chassis of the machine protects it against electrical hazards that may occur in the machine body.
  13. The CYD2-Y1000 semi-automatic single nozzle dense liquid filling machine can fill many types of liquids. The types of liquids include honey, molasses, pomegranate syrup, jam, shampoo, tahini, cream, hair lotion, tomato paste, acuka, garlic sauces, yogurt, and many other dense liquid products. Additionally, it can also handle many liquids such as fruit juice, water, turnip juice, liquid soap, milk, liquid oil, motor oil, and syrup.

CYD2-Y1000 - Optional Features That Can Be Added to 100-1000ml Double Nozzle Liquid Filling Machine

In addition to the features of the CYD2-Y1000 semi-automatic single nozzle dense liquid filling machine, you can add the different features you need to the machine. The main optional features in question are as follows:
  • The machine’s sensor can be produced to be trigger-based.
  • An optional counter that shows the number of products filled can be added.
  • The filling nozzles can be produced in different sizes according to need.

CYD2-Y1000 - Liquid Filling Machine 100-1000ml - Other Details

  • The machine is packaged in a way suitable for easy transport over long distances.
  • The machine you purchase can be delivered to your address at a reasonable price through our partnered shipping service. Alternatively, you can arrange shipping with your own preferred courier.
  • The machine is guaranteed for one year against manufacturing defects.
